Precise CNC Reciprocal Wire-cut EDM AR45
N-Spark series products not only uphold the quality assurance and high intelligence of NOVICK series products, but also improve the peripheral configuration and performance of the products.Adopting Ande Jianqi's quality assurance system and standards ensures reliable product quality and worry-free technical services, and solidly provides customers with convenient and easy-to-use profit-making tools.
| Project | Unit | AR45 |
| Overall dimension | mm | 2020x1700x2000 |
| Total weight of machine tool | kg | 2400 |
| Table size | mm | 660x480 |
| Height of workbench to ground | mm | 980 |
| XY axis travel | mm | 450x350 |
| UV Axis Travel | mm | 50x 50 |
| Z-axis travel | mm | Motor 280 |
| Maximum cutting taper | ± 6 °/80mm with guide | |
| Maximum cutting thickness | mm | 300 |
| Size of working fluid tank | mm | 950x550 |
| Maximum workpiece weight | kg | 500 |
| Maximum workpiece size | mm | 950x550x300 |
| Overall dimension of water tank | mm | 670 x460x620 (including water pump) |
| Water tank volume | L | 80 |
| Standard power supply | AC3x380V / AC1x220V 50/60Hz 2kVA | |
| Allowable Fluctuation | 380V±10% / 220V±10% 50±1Hz | |
| Full load current | A | 3 |
| Maximum machining current | A | 15 |
| Maximum processing speed | Mm²/min | 200 |
| optimum surface roughness | μm | Ra≤ 1.0 |
